DC CHARACTERISTICS

Symbol

Parameter Description

Test Conditions

Min.

Typ.

Max.

Unit

VCC

Operating Voltage

3.0

4.5

5.0

ISB

Standby Current

Vcc = 3.0V, I/O Open

—

µA

IOP

Operating Current

Vcc = 3.0V, I/O Open

—

100

µA

VIH

Input HIGH Voltage

Vcc = 3.0V

2.5

3.0

3.5

VIL

Input LOW Voltage

Vcc = 2.0V

–0.3

0.3

IOH

VOUT HIGH Operating Current

Vcc = 3.0V, VOUT = 3.0V

—

–12

—

IOL

VOUT LOW Operating Current

Vcc = 3.0V, VOUT = 0V

—

ICO

COUT Operating Current

Vcc = 3.0V, VCOUT = 0.7V

—

–2

—

ISTPH

STP HIGH Operating Current

Vcc = 3.0V, VSTP = 3.0V

—

–5

—

ISTPL

STP LOW Operating Current

Vcc = 3.0V, VSTP = 0V

—

ILED

LED Output Current

Vcc = 2.2V – 6.0V

ÐF/F

Frequency Stability

(FOSC [3V] – FOSC [3.5V]) / FOSC (3.0V)

——

SAMPLING FREQUENCY vs

ROSC FOR API8208A

Common Sampling Rate vs. Oscillator Resistor

Sampling Frequency

ROSC

KHz

Kohm

5.0

290

5.5

262

6.0

240

6.5

220

7.0

201

7.5

187

8.0

174

8.5

162

9.0

153

9.5

143

10.0

135

10.5

127

11.0

120

12.0

108

SAMPLING FREQUENCY vs

ROSC FOR API8208A

Common Resistors vs. Sampling Rate

Sampling Frequency

Rosc

KHz

KOhm

13.0

100

14.0

16.0

22.0
