10201 Rev B

CXOXHT

CXOMKHT

MAXIMUM

MAXIMUM

DIM

inches

mm

inches

mm

A

0.136

3.40

0.263

6.68

B

0.107

2.70

0.204

5.18

0.043

1.09

0.060

1.52

0.048

1.21

0.065

1.65

D

0.041

1.10

0.065

1.65

E

0.031

0.85

0.070

1.78

PIN CONNECTIONS

1. Enable/Disable (E) or No Connection (N)

2. Ground

3. Output

4.

V

DD

SUGGESTED LAND PATTERN

PACKAGE DIMENSIONS

DESCRIPTION

For high temperature, high stability and fast start-up

applications, Statek offers the AT crystal-based 32.768 kHz

CXOMKHT and CXOXHT oscillators. These oscillators are

designed to operate at temperatures up to 200

shock version is also offered that features 10,000 g shock

survivability. Other features include fast start-up time (0.8 ms

typical) and low current operation (500 µA at 25

FEATURES

High temperature operation up to 200

Overall 5 times improvement in total frequency stability

when compared to a typical tuning fork design

A High-Shock version that features 10,000 g shock

survivability is also offered

Excellent stability over temperature

Fast start-up

CMOS and TTL compatible

Optional output enable/disable

Low current

Hermetically sealed ceramic package

Full military testing available

APPLICATIONS

Industrial

Downhole instrumentation

Rotary shaft sensors

Underground boring tools

STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256 www.statek.com

HIGH TEMPERATURE OSCILLATORS

32.768 kHz

High Stability/Fast Start-up/High Shock

YS

TEM

CERTIFIC

AT

01

CXOXHT

CXOMKHT

CXOMKHT

CXOXHT

CXOMKHT

CXO

XHT
