AD8366
Rev. A | Page 11 of 28
0
10
20
30
40
50
60
–3
–2
–1
0
1
2
3
4
5
POUT PER TONE (dBm)
GAIN CODE 0
GAIN CODE 63
TA = +85°C
TA = +25°C
TA = –40°C
Figure 23. OIP3 vs. Output Power (POUT) at Minimum and Maximum Gain
Codes, 10 MHz Frequency
0
10
20
30
40
50
60
70
80
90
100
–8
–7
–6
–5
–4
–3
–2
–1
012345
POUT PER TONE (dBm)
GAIN CODE 0
GAIN CODE 63
TA = +85°C
TA = +25°C
TA = –40°C
Figure 24. OIP2 vs. Output Power (POUT) at Minimum and Maximum Gain
Codes, 10 MHz Frequency
–110
–105
–100
–95
–90
–85
–80
–75
–70
–65
–60
–5 –4
–3
–2
–1
01
2345678
POUT (dBm)
TA = +85°C
TA = +25°C
TA = –40°C
GAIN CODE 0
GAIN CODE 63
Figure 25. HD2 vs. Output Power (POUT) at Gain Code 0 and Gain Code 63,
10 MHz Frequency
–110
–100
–90
–80
–70
–60
–50
–40
–30
–20
–10
0
–3
–2
–1
012345
POUT PER TONE (dBm)
GAIN CODE 0
GAIN CODE 63
TA = +85°C
TA = +25°C
TA = –40°C
Figure 26. IMD3 vs. Output Power (POUT) at Minimum-to-Maximum Gain
Codes, 10 MHz Frequency
POUT PER TONE (dBm)
–100
–90
–80
–70
–60
–50
–40
–30
–20
–10
0
–8
–7
–6
–5
–4
–3
–2
–1
0
1
2
3
4
5
GAIN CODE 0
GAIN CODE 63
TA = +85°C
TA = +25°C
TA = –40°C
Figure 27. IMD2 vs. Output Power (POUT) at Minimum and Maximum Gain
Codes, 10 MHz Frequency
–120
–115
–110
–105
–100
–95
–90
–85
–80
–75
–70
–65
–60
–5
–4
–3
–2
–1
0
1
2
3
4
5
POUT (dBm)
TA = +85°C
TA = +25°C
TA = –40°C
GAIN CODE 0
GAIN CODE 63
Figure 28. HD3 vs. Output Power (POUT) for Gain Code 0 and Gain Code 63,
10 MHz Frequency
