Mechanical Dimension :

Features

DELTA ELECTRONICS, INC.

TEL: 886-3-3591968; FAX: 886-3-3591991

http://www.deltaww.com

SMT Power Inductor

HMP1360 Type

N

M

L

K

O

C

J

E

D

H

A

UNIT : mm/inch

D = 7.80 / 0.307

F = 2.50 / 0.098

G = 2.50 / 0.098

H = 8.00 / 0.315

J = 3.20 / 0.126

K = 7.00 / 0.276

L = 14.00 / 0.551

M = 3.70 / 0.146

124

G

F

1

UNIT : mm/inch

PART NO.

C (MAX)

E

N

O

B

A

HMP1360

12.70

0.5 / 0.50

0.02

13.00

0.5 / 0.512

0.02

6.00 / 0.236

2.40 / 0.094

11.20 / 0.441

4.40 / 0.173

HMP1360S

12.70

0.5 / 0.50

0.02

13.00

0.5 / 0.512

0.02

6.00 / 0.236

1.80 / 0.071

10.60 / 0.417

5.00 / 0.197

At 25

: 100KHz, 1V

1. Tolerance of inductance is

20%.

2. Isat is the DC current which cause the inductance drop to Li.

O

OO

rms

L

(uH)

Li

(uH) MIN

I

(Adc)

(m

) MAX

DCR

sat

I

(Adc)

1

3

2

RECOMMENDED PAD PATTERNS

HMP1360-0R5

0.50

0.40

1.0

40

45

HMP1360-R56

0.56

0.45

1.0

30

45

HMP1360M-0R6

0.60

0.48

1.0

35

45

HMP1360-1R0

1.00

0.80

1.3

30

35

HMP1360-1R0HS

1.00

0.80

2.5

40

25

HMP1360-1R2

1.20

0.96

1.3

25

35

HMP1360M-2R2

2.20

1.76

2.5

18

25

HMP1360M-2R4HS

2.40

1.50

6.6

30

15

HMP1360S-3R5HS

3.50

2.80

7.5

20

11

HMP1360S-4R7

4.70

3.76

7.5

16

11

RoHS compliant.

Low profile, SMD type.

High current.

Magnetic shielded.

High energy storage and low DCR.

Provided with embossed carrier tape packing.

Ideal for power source circuits, DC-DC converter, DC-AC inverters

inductor applications.

In addition to the standard versions shown here, customized inductors

are available to meet your exact requirements.
