RECOMMENDED PAD PATTERNS

A

B

C

E

D

1.6 / 0.063

2.34 / 0.092

3.32 / 0.131

Mechanical Dimension :

Features

O

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

84

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.

TEL: 886-3-3591968; FAX: 886-3-3591991

http://www.deltaww.com

SMT Power Inductor

HAH65 Type

Electrical Characteristics :

UNIT : mm/inch

A = 7.90 / 0.311 Max.

B = 7.00 / 0.276 Max.

C = 5.00 / 0.196 Max.

D = 1.40 / 0.055

E = 1.90 / 0.075

rms

L

(uH)

Li

(uH)

I

(Adc)

o

(m

) MAX

DCR

sat

I

(Adc)

1

3

2

1. Lo is the initial inductance and the tolerance of inductance is

20%.

2. Isat is the DC current which cause the inductance drop to Li.

O

OO

RoHS compliant.

Low profile, SMD type.

High current.

Magnetic shielded.

High energy storage and low DCR.

Provided with embossed carrier tape packing.

Ideal for power source circuits, DC-DC converter, DC-AC inverters

inductor applications.

In addition to the standard versions shown here, customized inductors

are available to meet your exact requirements.

HAH65-R68

0.68

0.60

3.2

22.0

17.0

HAH65-1R0

1.00

0.80

4.7

15.0

16.0

HAH65-1R5

1.50

1.20

5.5

16.0

15.0

HAH65-6R0

6.00

6.00

18.0

3.0

5.5
