4 / 15 page

E3Z

Nomenclature

Diffuse-reflective Models

E3Z-D6j

Stability indicator (green)

Operation selector

Operation indicator (orange)

Sensitivity adjuster

Through-beam Models

E3Z-T6j Receiver

Retroreflective Models

E3Z-R6j

Operation

OUTPUT CIRCUITS

Model

E3Z-T61/-T66/-R61/-R66/-D61/-D66/-D62/-D67

NPN output

Through-beam receiver

Retroreflective model

Diffuse reflective model

Through-beam emitter

Operation

indicator

Stability

indicator

Main

circuit

Orange

Green

100 mA

max.

Load

(Relay)

Brown

Black

Blue

Control output

12 to 24 VDC

Power indicator (orange)

Main

circuit

12 to 24 VDC

Brown

Blue

Model

E3Z-T81/-T86/-R86/-D81/-D86/-D82/-D87

PNP output

Through-beam receiver

Retroreflective model

Diffuse reflective model

Through-beam emitter

Operation

indicator

Stability

indicator

Main

circuit

Orange

Green

Brown

Black

Blue

Control output

12 to 24 VDC

100 mA

max.

Load

(Relay)

Power indicator (orange)

Main

circuit

12 to 24 VDC

Brown

Blue

Connector pin

arrangement

Pin 2 is open.

Pins 2, 4 are open.

TIMING CHARTS

Incident

Operation

indicator

(orange)

Output

transistor

Load

(relay)

Interrupted

OFF

Operate

Reset

(Between blue and black)

Incident

Operation

indicator

(orange)

Output

transistor

Load

(relay)

Interrupted

OFF

Operate

Reset

(Between blue and black)

Dark-ON (D-ON) Operation

Light-ON (L-ON) Operation
