Inductors for Power Circuits

Wound Ferrite

FEATURES

Magnetic shield type wound inductor for power circuits.

A DC-DC converter with top-class voltage conversion efficiency for similar products was achieved by optimizing the magnetic material

and configuration.

Low-profile product lineup with max. heights of 1.0mm, 1.2mm, and 1.5mm allowing for different usages.

High magnetic shield construction and compatible with high-density mounting.

Halogen-free compatible product.

APPLICATION

Smart phones, tablet terminals, HDDs, SSDs, DVCs, DSCs, mobile display panels, portable game devices, compact power supply

modules, other

PART NUMBER CONSTRUCTION

OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT

Overview of the VLF-M Series

VLF

252010

M

T

-

R47

N

Series name

L×W×H Dimensions

internal code

Packaging style

Inductance

Inductance

tolerance

(mm max.)

(μH)

252010

2.5×2.0×1.0

T

Taping

R47

0.47

M

±20%

252012

2.5×2.0×1.2

1R5

1.5

N

±30%

252015

2.5×2.0×1.5

220

22

302510

3.0×2.5×1.0

302512

3.0×2.5×1.2

302515

3.0×2.5×1.5

403210

4.0×3.2×1.0

403212

4.0×3.2×1.2

403215

4.0×3.2×1.5

504010

5.0×4.0×1.0

504012

5.0×4.0×1.2

504015

5.0×4.0×1.5

Type

Temperature range

Package quantity

Individual weight

Operating

Storage

（°C）

（°C）

(pieces/reel)

（g）

VLF252010MT

–40 to +105

–40 to +105

2000

0.017

VLF252012MT

–40 to +105

–40 to +105

2000

0.021

VLF252015MT

–40 to +105

–40 to +105

2000

0.027

VLF302510MT

–40 to +105

–40 to +105

2000

0.026

VLF302512MT

–40 to +105

–40 to +105

2000

0.033

VLF302515MT

–40 to +105

–40 to +105

2000

0.041

VLF403210MT

–40 to +105

–40 to +105

1000

0.048

VLF403212MT

–40 to +105

–40 to +105

1000

0.059

VLF403215MT

–40 to +105

–40 to +105

1000

0.072

VLF504010MT

–40 to +105

–40 to +105

1000

0.073

VLF504012MT

–40 to +105

–40 to +105

1000

0.089

VLF504015MT

–40 to +105

–40 to +105

1000

0.114

Product compatible with RoHS directive

Halogen-free

Compatible with lead-free solders

RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://www.tdk.co.jp/rohs/

Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
