Data Sheet
ADA4500-2
Rev. A | Page 7 of 24
ABSOLUTE MAXIMUM RATINGS
Table 3.
Parameter
Rating
Supply Voltage
6 V
Input Voltage
(V−) − 0.2 V to (V+) + 0.2 V
Differential Input Voltage1
(V−) − 0.2 V to (V+) + 0.2 V
Output Short-Circuit Duration
Indefinite
Storage Temperature Range
−65°C to +150°C
Operating Temperature Range
−40°C to +125°C
Junction Temperature Range
−65°C to +150°C
Lead Temperature (Soldering, 60 sec)
300°C
1 Differential input voltage is limited to 5.6 V or the supply voltage + 0.6 V,
whichever is less.
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
THERMAL RESISTANCE
θJA is specified for the worst-case conditions, that is, a device
soldered in a circuit board for surface-mount packages.
Table 4. Thermal Resistance
Package Type
θ
JA
θ
JC
Unit
8-Lead MSOP (RM-8)1
142
45
°C/W
8-Lead LFCSP (CP-8-12)2, 3
85
2
°C/W
1 Thermal numbers were simulated on a 4-layer JEDEC printed circuit board (PCB).
2 Thermals numbers were simulated on a 4 layer JEDEC PCB with the exposed
pad soldered to the PCB.
3 θ
JC was simulated at the exposed pad on the bottom of the package.
