DRA Series

High Power Density,

High Efficiency, Shielded Inductors

Magnetics Solutions

For Automotive Applications

User direction of feed

Ø1.50 Min.

Ø1.50 +0.1/-0.0

SECTION A-A

B0= 7.90 mm

A0= 7.90 mm

K0= 4.70 mm

4.00

2.00 ±0.1

1.75±0.10

7.50±0.1 16.00

±0.3

12.00

DRA74 Series

SECTION A-A

B0= 13.00mm

A0= 13.00 mm

K0= 4.90 mm

1.5 dia

+0.1/-0.0

11.5

1.75

2.0

16.00

1.5 dia

min

24.0

+/-0.3

User direction of feed

DRA124 Series

SECTION A-A

B0= 13.00 mm

A0= 13.00 mm

K0= 6.30 mm

1.5 dia

+0.1/-0.0

11.5

1.75

2.0

16.00

1.5 dia

min

24.0

+/-0.3

User dir ection of feed

DRA125 Series

Packaging Information

Ø1.50 Min.

Ø1.50+0.1/-0.0

SECTION A-A

B0= 7.90 mm

A0= 7.90mm

K0= 3.80mm

4.00

2.00 ±0.1

1.75±0.10

7.50±0.1 16.00

±0.3

User directionof feed

12.00

DRA73 Series

Dimensions are in millimeters.

Parts packaged on 13" Diameter reel,

1,350 parts per reel.

Parts packaged on 13" Diameter reel,

1,100 parts per reel.

Parts packaged on 13" Diameter reel,

750 parts per reel.

Parts packaged on 13" Diameter reel,

600 parts per reel.

SECTION A-A

B0= 13.00 mm

A0= 13.00mm

K0= 8.30mm

1.5 dia

+0.1/-0.0

11.5

1.75

2.0

20.00

1.5 dia

min

24.0

+/-0.3

User direction of feed

DRA127 Series

Parts packaged on 13" Diameter reel,

350 parts per reel.
