 5 / 32 page
background image
Data Sheet
ADP2441
Rev. A | Page 5 of 32
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
Rating
VIN to PGND
−0.3 V to +40 V
EN to AGND
−0.3 V to +40 V
SW to PGND
−0.3 V to +40 V
BST to PGND
−0.3 V to +45 V
VCC to AGND
−0.3 V to +6 V
BST to SW
−0.3 V to +6 V
FREQ, PGOOD, SS/TRK, COMP, FB to AGND
−0.3 V to +6 V
PGND to AGND
±0.3 V
Operating Junction Temperature Range
−40°C to +125°C
Storage Temperature Range
−65°C to +150°C
Lead Temperature (Soldering, 10 sec)
260°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
THERMAL RESISTANCE
θJA is specified for the worst-case conditions, that is, a device
soldered in a circuit board for surface-mount packages, and is
based on a 4-layer standard JEDEC board.
Table 3. Thermal Resistance
Package Type
θJA
θJC
Unit
12-Lead LFCSP
40
2.4
°C/W
