M24512-W M24512-R M24512-DR M24512-DF

Maximum rating

Doc ID 16459 Rev 26

23/40

Maximum rating

Stressing the device outside the ratings listed in Table 5 may cause permanent damage to

the device. These are stress ratings only, and operation of the device at these, or any other

conditions outside those indicated in the operating sections of this specification, is not

implied. Exposure to absolute maximum rating conditions for extended periods may affect

device reliability.

Table 5.

Absolute maximum ratings

Symbol

Parameter

Min.

Max.

Unit

Ambient operating temperature

–55

130

°C

TSTG

Storage temperature

–65

150

°C

TLEAD

Lead temperature during soldering

see note (1)

Compliant with JEDEC Std J-STD-020D (for small body, Sn-Pb or Pb assembly), the ST ECOPACK®

7191395 specification, and the European directive on Restrictions on Hazardous Substances (RoHS)

2002/95/EU.

°C

VIO

Input or output range

–0.50

6.5

IOL

DC output current (SDA = 0)

VCC

Supply voltage

–0.50

6.5

VESD

Electrostatic pulse (Human Body model)(2)

Positive and negative pulses applied on different combinations of pin connections, according to AEC-

Q100-002 (compliant with JEDEC Std JESD22-A114, C1=100 pF, R1=1500

Ω).

4000(3)

4000 V for new devices identified with process letters KB and 3000 V for previous devices identified with

process letters KA and AB.
