ADRF6704

Data Sheet

Rev. 0 | Page 10 of 36

TYPICAL PERFORMANCE CHARACTERISTICS

VS = 5 V; TA = 25°C; baseband I/Q amplitude = 1 V p-p differential sine waves in quadrature with a 500 mV dc bias; baseband I/Q

frequency (fBB) = 1 MHz; fPFD = 38.4 MHz; fREF = 153.6 MHz at +4 dBm Re:50 Ω (1 V p-p); 130 kHz loop filter, unless otherwise noted.

2500

2550

2600

2650

2700

2750

2800

2850

2900

LO FREQUENCY (MHz)

–40°C

+25°C

+85°C

Figure 4. Single Sideband (SSB) Output Power (POUT) vs.

LO Frequency (fLO) and Temperature; Multiple Devices Shown

2500

2550

2600

2650

2700

2750

2800

2850

2900

LO FREQUENCY (MHz)

–40°C

+25°C

+85°C

Figure 5. SSB Output 1dB Compression Point (OP1dB) vs. LO Frequency (fLO)

and Temperature; Multiple Devices Shown

–20

–15

–10

–80

–70

–60

–50

–40

–30

–20

–10

0.1

SECOND-ORDER DISTORTION (dBc)

BASEBAND INPUT VOLTAGE (Vp-p Differential)

–5

SSB OUTPUT POWER (dBm)

THIRD-ORDER DISTORTION (dBc)

CARRIER FEEDTHROUGH (dBm)

SIDEBAND SUPRESSION (dBc)

Figure 6. SSB Output Power, Second- and Third-Order Distortion, Carrier

Feedthrough, and Sideband Suppression vs. Baseband Differential Input

Voltage (fOUT = 2500 MHz)

2500

2550

2600

2650

2700

2750

2800

2850

2900

LO FREQUENCY (MHz)

4.75V

5.25V

Figure 7. Single Sideband (SSB) Output Power (POUT) vs.

LO Frequency (fLO) and Power Supply; Multiple Devices Shown

2500

2550

2600

2650

2700

2750

2800

2850

2900

LO FREQUENCY (MHz)

4.75V

5.25V

Figure 8. SSB Output 1dB Compression Point (OP1dB) vs. LO Frequency (fLO)

and Power Supply

–20

–15

–10

–80

–70

–60

–50

–40

–30

–20

–10

0.1

SECOND-ORDER DISTORTION (dBc)

BASEBAND INPUT VOLTAGE (Vp-p Differential)

–5

SSB OUTPUT POWER (dBm)

SIDEBAND SUPRESSION (dBc)

THIRD-ORDER DISTORTION (dBc)

CARRIER FEEDTHROUGH (dBm)

Figure 9. SSB Output Power, Second- and Third-Order Distortion, Carrier

Feedthrough, and Sideband Suppression vs. Baseband Differential Input

Voltage (fOUT = 2900 MHz)
