U74ACT86

CMOS IC

www.unisonic.com.tw

1 of 4

Copyright © 2008 Unisonic Technologies Co., Ltd

QW-R126-007.B

QUAD EXCLUSIVE OR GATE

DESCRIPTION

The U74ACT86 consists of four EXCLUSIVE OR GATE it

provides the function Y=A♁B, the device is designed to interface

directly High Speed CMOS systems with TTL, NMOS and CMOS

output voltage levels.

FEATURES

* Operation voltage range: 4.5~5.5V

* Low power dissipation:

* High noise immunity

* Compatible with TTL output

*Pb-free plating product number:

U74ACT86L

ORDERING INFORMATION

Ordering Number

Normal

Lead Free Plating

Package

Packing

U74ACT86-D14-T

U74ACT86L-D14-T

DIP-14

Tube

U74ACT86-S14-T

U74ACT86L-S14-T

SOP-14

Tube

U74ACT86-S14-R

U74ACT86L-S14-R

SOP-14

Tape Reel

U74ACT86-P14-T

U74ACT86L-P14-T

TSSOP-14

Tube
