KPY 51-RK

KPY 57-RK

Semiconductor Group

2

1) Frontside coupling applies pressure onto chip face.

Rearside coupling applies pressure through Kovar centre tube.

Absolute Maximum Ratings

Parameter

Symbol

Limit Values

1)

Unit

Frontside Rearside

Pressure overload

KPY 51 RK

KPY 52 RK

KPY 53 RK

KPY 54 RK

KPY 55 RK

KPY 56 RK

KPY 57 RK

P

MAX

2

6

10

16

30

75

100

2

6

10

16

30

40

70

bar

Operating temperature range

T

A

− 40 …+ 125

˚C

Storage temperature range

T

stg

− 50 …+ 150

˚C

Supply voltage

V

IN

12

V

Electrical Characteristics

at

T

Parameter

Symbol

Limit Values

Unit

min.

typ.

max.

Bridge resistance

R

B

4

−

8k

Ω

Sensitivity

KPY 51 RK

KPY 52 RK

KPY 53 RK

KPY 54 RK

KPY 55 RK

KPY 56 RK

KPY 57 RK

s

16.8

11.0

5.6

4.0

1.8

0.88

0.47

24.0

15.0

8.8

6.0

2.6

1.2

0.67

32.0

24.0

12.5

9.0

4.0

2.0

1.0

mV/

Vbar

Output voltage

KPY 51 RK

KPY 52 RK

KPY 53 RK

KPY 54 RK

KPY 55 RK

KPY 56 RK

KPY 57 RK

V

fin

21

33

45

80

90

110

140

30

45

70

120

130

150

200

40

72

100

180

200

250

300

mV
