RF2046
Rev A5 010110
4
Absolute Maximum Ratings
Parameter
Rating
Unit
Supply Current
75
mA
Input RF Power
+15
dBm
Operating Ambient Temperature
-40 to +85
°C
Storage Temperature
-60 to +150
°C
Parameter
Specification
Unit
Condition
Min.
Typ.
Max.
Overall
T=25 °C, VD=3.5V, ICC=35mA
Frequency Range
DC to 3000
MHz
Gain
22.9
dB
Freq= 100MHz
22.2
dB
Freq= 1000MHz
18
20.8
dB
Freq=2000MHz
19.2
dB
Freq= 3000MHz
Gain Flatness
±1.1
dB
100MHz to 2000MHz
Noise Figure
3.8
dB
Freq= 2000MHz
Input VSWR
1.7:1
In a 50
Ω system, DC to 3000MHz
Output VSWR
1.7:1
In a 50
Ω system, DC to 3000MHz
Output IP3
+23
dBm
Freq=2000MHz±100kHz, PTONE=-18dBm
Output P1dB
+12.1
dBm
Freq=2000MHz
Reverse Isolation
23.2
dB
Freq=2000MHz
Thermal
ICC=35mA, PDISS=120mW
ThetaJC
199
°C/W
Maximum junction temperature
109
°C
Mean Time Between Failures
2.0x104
years
TAMB=+85°C
Mean Time Between Failures
1.4x107
years
TAMB=+25°C
Mean Time Between Failures
5.3x1011
years
TAMB=-40°C
Power Supply
With 22
Ω bias resistor
Operating Voltage
3.0
3.5
4.0
V
At pin 3 with ICC=35mA
Operating Current
35
mA
