3 / 28 page  ADL5902 Rev. 0 | Page 3 of 28 SPECIFICATIONS VS = 5 V, TA = 25°C, ZO = 50 Ω, single-ended input drive, RT = 60.4 Ω, VOUT connected to VSET, VTGT = 0.8 V, CLPF = 0.1 µF. Negative current values imply that the ADL5902 is sourcing current out of the indicated pin. Table 1. Parameter Test Conditions Min Typ Max Unit OVERALL FUNCTION Frequency Range 50 to 9000 MHz RF INPUT INTERFACE Pins INHI, INLO, ac-coupled Input Impedance Single-ended drive, 50 MHz 2000 Ω Common Mode Voltage 2.5 V 100 MHz ±1.0 dB Dynamic Range CW input, TA = +25°C, VTADJ = 0.5 V 63 dB Maximum Input Level, ±1.0 dB Calibration at −60 dBm, −45 dBm, and 0 dBm 3 dBm Minimum Input Level, ±1.0 dB Calibration at −60 dBm, −45 dBm, and 0 dBm −60 dBm Deviation vs. Temperature Deviation from output at 25°C −40°C < TA < +85°C; PIN = 0 dBm −0.11/+0.25 dB −40°C < TA < +85°C; PIN = −45 dBm −0.22/+0.15 dB −40°C < TA < +125°C; PIN = 0 dBm −0.35/+0.25 dB −40°C < TA < +125°C; PIN = −45 dBm −0.22/+0.15 dB Logarithmic Slope −45 dBm < PIN < 0 dBm; calibration at −45 dBm and 0 dBm 53.8 mV/dB Logarithmic Intercept −45 dBm < PIN < 0 dBm; calibration at −45 dBm and 0 dBm −62.1 dBm 700 MHz ±1.0 dB Dynamic Range CW input, TA = +25°C,VTADJ = 0.4 V 61 dB Maximum Input Level, ±1.0 dB Calibration at −60 dBm, −45 dBm, and 0 dBm 1 dBm Minimum Input Level, ±1.0 dB Calibration at −60 dBm, −45 dBm, and 0 dBm −60 dBm Deviation vs. Temperature Deviation from output at 25°C −40°C < TA < +85°C; PIN = 0 dBm +0.3/−0.2 dB −40°C < TA < +85°C; PIN = −45 dBm −0.1/0 dB −40°C < TA < +125°C; PIN = 0 dBm +0.3/−0.4 dB −40°C < TA < +125°C; PIN = −45 dBm −0.1/0 dB Logarithmic Slope −45 dBm < PIN < 0 dBm; calibration at −45 dBm and 0 dBm 53.7 mV/dB Logarithmic Intercept −45 dBm < PIN < 0 dBm; calibration at −45 dBm and 0 dBm −62.8 dBm 900 MHz ±1.0 dB Dynamic Range CW input, TA = +25°C, VTADJ = 0.4 V 61 dB Maximum Input Level, ±1.0 dB Calibration at −60 dBm, −45 dBm, and 0 dBm 1 dBm Minimum Input Level, ±1.0 dB Calibration at −60 dBm, −45 dBm, and 0 dBm −60 dBm Deviation vs. Temperature Deviation from output at 25°C −40°C < TA < +85°C; PIN = 0 dBm +0.3/−0.2 dB −40°C < TA < +85°C; PIN = −45 dBm 0/−0.1 dB −40°C < TA < +125°C; PIN = 0 dBm +0.3/−0.4 dB −40°C < TA < +125°C; PIN = −45 dBm 0/−0.1 dB Logarithmic Slope −45 dBm < PIN < 0 dBm; calibration at −45 dBm and 0 dBm 53.7 mV/dB Logarithmic Intercept −45 dBm < PIN < 0 dBm; calibration at −45 dBm and 0 dBm −62.7 dBm |
|
