1 / 8 page  APTM120U10SCAVG www.microsemi.com 1 – 8 D DK S SK G G, SK and DK terminals are for control signals only (not for power) D S DK SK SK G All ratings @ Tj = 25°C unless otherwise specified These Devices are sensitive to Electrostatic Discharge. Proper Handling Procedures Should Be Followed. See application note APT0502 on www.microsemi.com VDSS = 1200V RDSon = 100mΩ typ @ Tj = 25°C ID = 116A @ Tc = 25°C Application • Welding converters • Switched Mode Power Supplies • Uninterruptible Power Supplies • Motor control Features • Power MOS 7 ® MOSFETs - Low RDSon - Low input and Miller capacitance - Low gate charge - Avalanche energy rated - Very rugged • SiC Parallel Schottky Diode - Zero reverse recovery - Zero forward recovery - Temperature Independent switching behavior - Positive temperature coefficient on VF • Kelvin source for easy drive • Kelvin drain for voltage monitoring • Very low stray inductance - Symmetrical design - M5 power connectors - M3 power connectors • High level of integration • AlN substrate for improved MOSFET thermal performance Benefits • Outstanding performance at high frequency operation • Direct mounting to heatsink (isolated package) • Low junction to case thermal resistance • Low profile • RoHS Compliant Single switch Series & SiC parallel diodes MOSFET Power Module |
