Industrial Panel PCs
Features
Specifications
General
Button Control
Membrane Keypad 1 43 operating keys
Membrane Keypad 2 10 programmable macro function
keys
Certifications
BSMI, CCC, CE, FCC
Dimensions (W x H x D) 482 x 354.8 x 276.5 mm (18.97" x 13.96" x 10.9")
Enclosure
Front Panel – Die-cast
Chassis – anti-rust
Mounting
19" Rack
Power Input
100-240 VAC, 10 A, 60-50 Hz
Power Ouput
+ 5 V @ 30 A, +12 V @ 15 A, +3.3 V @ 28 A,
-5 V @ 0.3 A, -12 V @ 0.8 A, +5 VSB @ 2 A
Power Supply
Watt: 300 W, MTBF: 100,000 hrs
Weight
18Kg (39.7 lbs)
System Hardware
Slots
2 ISA, 10 PCI, 2 PICMG
Size
315 x 260 mm (12.4" x 10.24")
PCI Bridge
Pericom PI7C8150MA
PCI Slot
Primary: 3 slots,
Secondary: 7 slots
Storage (Optional)
1 x 3.5" HDD
1 x FDD
1 x 5.25" CD-ROM
LCD Display
Backlight Life
50,000 hrs
Contrast Ratio
450 : 1
Display Size
15"
Display Type
XGA TFT LCD
Luminance
250 cd/m2
Max. Colors
16.2 M (RGB 6-bit + FRC data)
Max. Resolution
1024 x 768
OSD Control
ON/OFF, Brightness down, up (behind the front panel)
Viewing Angle (H/V°)
140/120
Touchscreen (Optional)
Lifespan
10 million with a silicone rubber of R8 finger, writing
rate is by 250g at 2 times/s
Light Transmission
> 80% (AMT)
Type
8-wire Resistive
Environment
Humidity
5 ~ 85% RH @ 40° C (non-condensing)
Ingress Protection
Front panel NEMA4/IP65
Operating Temperature 0 ~ 50° C (32 ~ 122° F)
Storage Temperature
-20 ~ 60° C (-4 ~ 140° F)
Vibration Protection
5 ~ 500 Hz, 1 GRMS random vibration (operating)
Ordering Information
IPPC-7158B-X1AE
15" Ind. Panel PC, Backplane, 14 x Slot, Keypad
IPPC-7158B-R1AE
15" Ind. Panel PC, Backplane, 14 x Slot, Keypad, TS
IPPC-7158B
15" XGA TFT LCD Passive Backplane
Industrial Panel PC with 14 Expansion
Slots and Keypad
15" XGA TFT LCD with touchscreen (optional) provides vivid, sharp images
Offers 14 expansion slots for PCI, PICMG and ISA
Detachable side-open front panel makes maintenance fast & easy
Programmable membrane function keys for varied application access
Heavy-duty design with anti-rust chassis with aluminum front panel which
meet NEMA4/IP65
One front accessible USB 2.0 port
Flexible modular chassis design with upgradable industrial motherboard
Introduction
The IPPC-7158 is a brand new Industrial Panel PC with 15" XGA TFT LCD. It supports passive backplane boards with ISA/PCI/PICMG expansion slots. IPPC-7158 provides many
powerful features such as a detachable side-open front panel, a front-accessible USB 2.0 port, programmable membrane function keys & touch pad, OSD Control, NEMA4/IP65
compliant aluminum front panel, and optional analog resistive touchscreen (USB Interface).
NEW
