Industrial Monitors
Features
FPM-3191G 19"SXGAIndustrialMonitorwithResistive
Touchscreen, Direct-VGA and DVI Ports
Specifications
General
Button Controls
OSD (Onscreen Display) control pad on front panel
Certification
BSMI, CCC, CE, FCC
Dimension (W x H x D) 482 x 399 x 66 mm (18.9" x 15.7" x 2.6")
Enclosure
Front panel: Aluminum with coating
Rear cover: Stainless steel chassis
Mounting
Panel, wall, desktop, VESA arm & 19" rackmount
Power Input
External 60 W power adapter, with AC 100 V ~ 240 V
input and DC +12 V @ 5 A output
Video Port
VGA & DVI-D Port
Weight (Net)
10.65 kg (23.46 lbs)
LCD Display
Display Type
SXGA TFT LCD (AUO)
Display Size
19"
Max. Resolution
1280 x 1024
Max. Color
16.2 M
Viewing Angle (H/V°)
178/178
Luminance (cd/m2)
300
Backlight Life (hrs)
50,000
Contrast Ratio
1000 : 1
19" SXGA TFT LCD with resolution up to 1280 x 1024
Robust design with stainless steel chassis and aluminum front panel
Anti-reflective screen with tempered glass
Supports stainless steel front panel (customization)
OSD control pad on front panel
Supports industrial 24-48 VDC power input (optional)
Supports tranflective LCD technology (customization)
Supports panel, wall, desktop, rack or VESA arm mounting
Front panel is NEMA4/IP65 compliant
Touchscreen (Optional)
Sensor
ELO
Driver
ELOTOUCH
Type
5-wire Resistive
Interface
RS-232 and USB
Lifespan
35 million touches at a single point
Light Transmission
80% ±5
OS Support
DOS, Windows® 2000/XP/CE/Vista, Linux
Power Consumption
+5 V @ 100 mA
Touch Resolution
Linearity
Environment
Operation Temperature 0 ~ 50° C (32 ~ 122° F)
Storage Temperature
-20 ~ 60° C (-4 ~ 140° F)
Humidity (Storage)
10 ~ 90% non-condensing
Waterproof
Front panel is NEMA4/IP65 compliant
Vibration
5 ~ 500 Hz, 1 Grms (Operating, Random)
Ordering Information
FPM-3191G-XCE
19" SXGA Ind. Monitor
FPM-3191G-RCE
19" SXGA Ind Monitor w/Resistive TS (RS-232 & USB)
PWR-246E
DC to DC Converter w/24-48VDC Power Input
Introduction
FPM-3191G is a 19" color TFT LCD flat panel monitor specifically designed for industrial applications. With a viewing size as large as 19", it presents an ample display area as well as
vivid and sharp images for your HMI. It features Direct-VGA signal transmission and the onscreen display function makes it easy to adjust the images on the screen. The stainless steel
chassis and the NEMA4/IP65 compliant aluminum front panel enable installation in applications with water and dust. An optional stainless steel front panel is available by request.
