Ultra-Miniature SMT Slides

Series SS3

TERMINAL SPACING

POLES & CIRCUITS

CONTACT MATERIALS & RATING

Complete explanation of operating range in Supplement section.

Gold over Silver/Phosphor Bronze

Logic Level

0.4VA maximum @ 28V AC/DC maximum

4

H

Side Actuated

A

ACTUATION

SS312

SS314

(2.0)

.079

(1.2)

.049

(1.5)

.059

(4.0)

.157

(9.2)

.362

(1.4)

.055

(0.17) Typ

.0067

(0.6) Typ

.024

(2.0) Typ

.079

(4.2)

.165

(12.5)

.492

(1.4)

.055

(0.17) Typ

.0067

(0.6) Typ

.024

(2.0) Typ

.079

(2.0) Typ

.079

(1.0) Typ

.039

(1.7) Typ

.067

3

2

1

(9.8)

.386

(1.7)

.067

(2.55)

.1004

(5.6)

.220

(2.0) Typ

.079

(1.0) Typ

.039

(1.7) Typ

.067

3

2

1

(13.1)

.516

(1.7)

.067

(2.55)

.1004

(5.6)

.220

4

5

Metric 2.0mm x 2.0mm

Slide Position

Connected Terminals

Throw & Schematics

Pole

Model

Right

Center

Left

Right Center

Left

Note: Terminal numbers are not actually on switch.

SP

SS312S

ON

NONE

ON

2-1

OPEN

2-3

SPDT

SP

SS314M

ON

OFF

ON

3-5

4-2

3-1

SPDT

ON

ON

ON

3-5

3-4

3-1

SP3T

1

3

2 (COM)

1

4

5

3 (COM)

2

External Connection

1

4

5

3 (COM)

2

External connection

must be made during

installation to create

ON-ON-ON circuit.
