NKK Switches • email: sales@nkkswitches.com • Phone (480) 991-0942 • Fax (480) 998-1435 • www.nkkswitches.com

11-07

8mm Process Sealed SMT DIP Rotaries

Series ND3

For Upright & Upright with Bracket (Codes P & B with K Actuator)

Each tape-reel of 530 pockets contains 500 switches

Minimum Leader Length: 9.05” (230mm)

Minimum Trailer Length: 6.30” (160mm)

PACKAGING (CONTINUED)

For Right Angle (Code H with F or K Actuator)

Each tape-reel of 550 pockets contains 500 switches

Minimum Leader Length: 9.05” (230mm)

Minimum Trailer Length: 6.30” (160mm)

For Upright & Upright with Bracket (Codes P & B with F Actuator)

Each tape-reel of 550 pockets contains 500 switches

Minimum Leader Length: 9.05” (230mm)

Minimum Trailer Length: 6.30” (160mm)

Reel Dimensions

Tape Dimensions

(13.0) Dia

.512

(2.0) Typ

.079

(21.0) Dia

.827

Overall Dia (330.0)

13.0

(78.49) Dia

3.090

(2.0)

.079

(24.4)

.961

Direction of Feed

(1.5) Dia Typ

.059

(4.0) Typ

.157

(16.0) Typ

.630

(2.0) Typ

.079

(1.75)

.069

(11.5)

.453

(24.0)

.945

(10.35) Typ

.4075

7 8

(5.5)

.217

(6.1)

.240

(10.6)

.417

(0.5)

.020

(78.49) Dia

3.090

(2.0)

.079

(24.4)

.961

(13.0) Dia

.512

(2.0) Typ

.079

(21.0) Dia

.827

Overall Dia (330.0)

13.0

Direction of Feed

(4.0) Typ

.157

(16.0) Typ

.630

(2.0) Typ

.079

(1.75)

.069

(11.5)

.453

(24.0)

.945

(10.35) Typ

.4075

3456

(1.5) Dia Typ

.059

(8.6)

.339

(9.3)

.366

(10.6)

.417

(0.5)

.020

(13.0) Dia

.512

(2.0) Typ

.079

(21.0) Dia

.827

Overall Dia (330.0)

13.0

(78.49) Dia

3.090

(2.0)

.079

(24.4)

.961

(8.1)

.319

(8.7)

.343

(10.7)

.421

(0.5)

.020

(24.0)

.945

(16.0) Typ

.630

(11.5)

.453

Direction of Feed

(6.3) Typ

.248

(4.0) Typ

.157

(10.9) Typ

.429

(2.0) Typ

.079

(1.75)

.069

(1.5) Dia Typ

.059

Reel Dimensions

Tape Dimensions

Reel Dimensions

Tape Dimensions
