Elektronische Bauelemente

SCS4148WS

Surface Mount Fast Switching Diode

ELECTRICAL CHARACTERISTICS (Ta=25

)

TYPE NUMBER

SYMBOL

Min.

Max.

UNITS

Test Condition

Reverse Breakdown Voltage

75

-

V

0.715

0.855

1.0

Forward Voltage (Note 2)

-

1.25

V

1.0

µA

50

µA

30

µA

Peak Reverse Current (Note 2)

-

25

nA

Total Capacitance

-

2.0

pF

Reverse Recovery Time

-

4.0

ns

NOTES:

1. Part mounted on FR-4 PC board with recommended pad layout,

2. Short duration test pulse used to minimize self-heating effect.

RATING AND CHARACTERISTIC CURVES

http://www.SeCoSGmbH.com/

Any changing of specification will not be informed individual

0

100

0

25

50

75

125

100

150

T , AMBIENT TEMPERATURE (°C)

A

Fig. 1 Power Derating Curve

300

200

10

1.0

100

1000

0.1

0.01

0

1

2

V , INSTANTANEOUS FORWARD VOLTAGE (V)

F

Fig. 2 Forward Characteristics

1

10

100

1000

10,000

0

100

200

T , JUNCTION TEMPERATURE (°C)

j

Fig. 3 Leakage Current vs Junction Temperature

V = 20V

R

01-Jun-2002 Rev. A

Page 2 of 2
