P7600

ETALDOC 826/4

Page 2 of 3

July 2005

SPECIFICATIONS

Electrical

Part Number

Inductance (µH)

(1)

DCR (mΩ) Max

(2)

(3)

P7600-R68M

0.68±20%

1.8

26

22

P7600-1R2M

1.2±20%

2.8

20

16

P7600-1R8M

1.8±20%

3.9

16

12

P7600-2R7M

2.7±20%

4.8

14

10

Notes

1. Inductance measured at 100kHz, 100mV.

2. Rated current is the current at which the temperature rise is 45ºC.

4. Operating temperature -25ºC to +105ºC.

5. For non-standard inductance values, please contact Profec.

2.7µH

1.8µH

1.2µH

0.68µH

5

101520

253035

40

DC CURRENT(A)

0.5

1.0

1.5

2.0

2.5

3.0

0

20% Inductance loss

Temperature limited (45°C) rated current

10% Inductance loss

Fig. 1

Effect of DC Current on Inductance
