Section 2 CPU
Rev. 2.00 Sep. 24, 2008 Page 50 of 1468
REJ09B0412-0200
2.7
Instruction Set
The H8SX CPU has 87 types of instructions. The instructions are classified by function as shown
in table 2.1. The arithmetic operation, logic operation, shift, and bit manipulation instructions are
called operation instruction in this manual.
Table 2.1
Instruction Classification
Function
Instructions
Size
Types
MOV
B/W/L
MOVFPE, MOVTPE
B
POP, PUSH*
1
W/L
LDM, STM
L
Data transfer
MOVA
B/W*
2
6
EEPMOV
B
MOVMD
B/W/L
Block transfer
MOVSD
B
3
ADD, ADDX, SUB, SUBX, CMP, NEG, INC, DEC
B/W/L
DAA, DAS
B
ADDS, SUBS
L
MULXU, DIVXU, MULXS, DIVXS
B/W
MULU, DIVU, MULS, DIVS
W/L
MULU/U*
6, MULS/U*6
L
EXTU, EXTS
W/L
TAS
B
MAC*
6
—
LDMAC*
6, STMAC*6
—
Arithmetic
operations
CLRMAC*
6
—
27
Logic operations
AND, OR, XOR, NOT
B/W/L
4
Shift
SHLL, SHLR, SHAL, SHAR, ROTL, ROTR, ROTXL, ROTXR
B/W/L
8
BSET, BCLR, BNOT, BTST, BAND, BIAND, BOR, BIOR,
BXOR, BIXOR, BLD, BILD, BST, BIST
B
BSET/EQ, BSET/NE, BCLR/EQ, BCLR/NE, BSTZ, BISTZ
B
Bit manipulation
BFLD, BFST
B
20
