Electrical characteristics
STLS2F01
40/48
Table 19.
Input setup and hold time
(Test Conditions: SYSCLK=100 MHz, PCICLK=66 MHz, CoreClk=1000 MHz)
Parameter
Min
Tpy
Max
Unit
PCI_* Signals Setup Time
3.0
ns
PCI_* Signals Hold Time
0.0
ns
LIO_* Signals Setup Time
3.0
ns
LIO_* Signals Hold Time
0.0
ns
Table 20.
Output delay time
(Test Conditions: SYSCLK=100 MHz, PCICLK=133 MHz, CoreClk=1000 MHz)
Parameter
Min
Typ
Max
Unit
PCI_* Signals Effective Delay
0.7
3.8
ns
LIO_* Signals Effective Delay
1.5
6.0
ns
DDDR2_A*/RAS*/CAS*/WE*/CS*/CKE*/ODT*
Signals Effective Delay
1.5
ns
DDR2_DQ*/DQM* Effective Delay
0.75
ns
Table 21.
JTAG parameters
(Test Condition: TCK = 100 MHz)
Parameter
Min
Typ
Max
Unit
TCK high level time
2
5
8
ns
TCK low level time
2
8
ns
TCK rising time
1
1
ns
TCK falling time
1
1
ns
TRST pulse width
10
ns
TDI,TMS setup time
3.5
4.4
ns
TDI,TMS hold time
2.5
5.5
ns
TDO output effective delay
1.28
ns
TDO output disable delay
1.28
ns
