ADG852

Rev. 0 | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

−0.3 V to +6 V

Analog Inputs1

Digital Inputs1

whichever occurs first

Peak Current, S or D Pins

500 mA (pulsed at 1 ms,

10% duty cycle max)

Continuous Current, S or D Pins

300 mA

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Junction Temperature

150°C

Mini LFCSP

3-Layer Board

131.6°C/W

Reflow Soldering, Pb-Free

Peak Temperature

260(+0/−5)°C

Time at Peak Temperature

10 sec to 40 sec

should be limited to the maximum ratings given.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Only one absolute maximum rating can be applied at any

one time.

ESD CAUTION
