AD8506/AD8508

Rev. A | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

5.5 V

Input Voltage

Input Current1

±10 mA

Differential Input Voltage2

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

limited to 10 mA or less whenever the input signal exceeds the power

supply rail by 0.5 V.

is less.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

soldered in a circuit board for surface-mount packages. This

was measured using a standard two-layer board.

Table 4. Thermal Resistance

Package Type

Unit

8-Lead MSOP (RM-8)

190

44

°C/W

14-Lead TSSOP (RU-14)

180

35

°C/W

ESD CAUTION
