2 / 5 page  3.0A Sintered Glass Passivated Super Fast Rectifier Rev. A/AH 2008-06-03 EGF3AB – EGF3KB www.taitroncomponents.com Page 2 of 5 Fig.1- Forward Current Derating Curve Lead Temperature (°C) Fig.2-Max. Non-Repetitive Forward Surge Current Number of Cycles at 60Hz Note: Thermal resistance from junction to ambient P.C.B mounted on 0.2x0.2” (5.0x5.0mm) copper pad areas. Typical Characteristics Curves Symbol Description EGF3AB EGF3BB EGF3DB EGF3GB EGF3JB EGF3KB Unit Conditions VF Maximum Instantaneous Forward Voltage 0.95 1.25 1.7 2.2 V IF=3.0 A 5.0 TA=25° C IR Maximum DC Reverse Current at Rated DC Blocking Voltage 120 µA TA=125° C Trr Maximum Reverse Recovery Time 35 nS IF=0.5A, IR=1.0A, Irr=0.25A CJ Typical Junction Capacitance 45 pF VR=4V, f=1MHz RthJA Typical Thermal Resistance 16 °C / W Note TJ,TSTG Operating junction and Storage Temperature Range -55 to +175 ° C |
|
|
