Datasheet

TC-38

Nov-23

A flexible magnetic strip thermocouple capable of being attached to most

ferro-magnetic surfaces, the large area of the magnet ensures good

adhesion allowing simplicity of installation.

Useful in a wide range of temperature monitoring applications,

particularly in test and development.

Specifications

General Description

Ideal for ferrous metal surface measurement

Thermocouple

Junction

Grounded measuring junction

Magnet

50 x 25 x 1mm magnetic strip

Cable Length

1 or 2 metre

Cable Type

PTFE insulated wires, twin twisted

Termination Type

Miniature flat pin plug, colour coded in accordance IEC

584

Max. Temperature

100°C

Min. Temperature

-50°C

Ordering Information

Type

Cable

Length

Termination

Manufacturers Code

Farnell Order

Code

K

1m

Miniature Plug

FMS-K-1M-MP

3584281

K

2m

Miniature Plug

FMS-K-2M-MP

7077725
