LTRB RASF

DATASHEET

DATASHEET

2 | Version 1.9 | 2024-11-04

Multi Chip LED

LTRB RASF

To fulfill the needs for pachinko- and gaming applications, this

product is especially designed to achieve easy white binning

and to reach high ESD level. The chips are configurated in a

triangle to get best color mixing already in the package.

Applications

- Appliances & Tools

- Entertainment

Features

- Package: SMT package, silicone resin

- Chip technology: Thinfilm / UX:3

- Typ. Radiation: 120° (Lambertian emitter)

- Color: λ

dom = 530 nm (● true green); λdom = 621 nm (● red); λdom = 465 nm (● blue)

- Color: x = 0.249, y = 0.208. acc. to CIE 1931 (white)

- Luminous Intensity: 2.010...3.550 mcd (white), typ. 2.000 mcd (true green), typ. 800 mcd (red), typ. 330

mcd (blue)

- ESD-withstand voltage: up to 8 kV acc. to JESD22-A114-D
