LTRB R37G

DATASHEET

DATASHEET

2 | Version 1.4 | 2025-12-03

Multi Chip LED

LTRB R37G

This device was designed for low profile consumer applications.

The 4-pin common anode technology emits an additive mixture

of red, green and blue color by independent driving of each

chip. Very compact package size and low z-height to support

highly integrated consumer applications in displays or accents.

Device is white binned.

Applications

- Entertainment

Features

- Package: SMT package, epoxy resin

- Chip technology: Volume emitter on Sapphire (AlInGaN) / Volume emitter on Sapphire (AlInGaN)

- Typ. Radiation: 120° (Lambertian emitter)

- Color: λ

dom = 530 nm (● true green); λdom = 623 nm (● red); λdom = 472 nm (● blue)

- ESD: 500 V acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 1B)

- Color: x = 0.249, y = 0.208. acc. to CIE 1931 (white)

- Luminous Intensity: 159...280 mcd (white), typ. 130 mcd (true green), typ. 45 mcd (red), typ. 25 mcd

(blue)
