EJ1

3

Characteristics

*1. The indication of K thermocouples in the −200 to 1,300°C range, T and N thermocouples at a temperature of −100°C or less, and U and L

thermocouples at any temperature is ±2°C ±1 digit maximum. The indication of B thermocouples at a temperature of 400°C or less is

unrestricted. The indication of R and S thermocouples at a temperature of 200°C or less is ±3°C ±1 digit max.

W = (±0.5% of indication value (PV) or ±3°C, whichever is greater) ±1 digit max. PLII = (±0.5% of indication value (PV) or ±2°C, whichever is

greater) ±1 digit max.

The indication accuracy for K thermocouples in the

−199.9 to 999.9°C range

is (±0.5% of indication value (PV) or ±1°C, whichever is

greater) ±10 digit maximum. However, at a temperature of -100°C or less, it is ±2°C ±10 digit maximum.

*2. “EU” stands for Engineering Unit. The location of the decimal point depends on the type of sensor that is selected.

If the decimal point locations is set to 0 (****), however, it will be treated as if it were set to 1 (***.*).

*3. B, R, S, and W sensors: 0.2°C/Ω max. (100 Ω max.)

Indication accuracy

Thermocouple input/platinum resistance thermometer input:

(±0.5% of indication value (PV) or ±1°C, whichever is greater) ±1 digit max.

*1

Analog input: ±0.5% FS ±1 digit max.

CT input:

±5% FS ±1 digit max.

Hysteresis

0.1 to 999.9 EU (in units of 0.1 EU)

*2

Proportional band (P)

0.1 to 999.9 EU (in units of 0.1 EU)

*2

Integral time (I)

0 to 3,999 s (in units of 1 s)

Derivative time (D)

0.0 to 999.9 s (in units of 0.1 s)

Control period

0.5 s, 1 to 99 s (in units of 1 s)

Manual reset value

0.0% to 100.0% (in units of 0.1%)

Alarm setting range

−1,999 to 9,999 (decimal point position depends on input type)

Sampling period

250 ms

Influence of signal source

resistance

Thermocouple:

0.1°C (0.2°F)/

Ω max. (100 Ω max per line) *3

Platinum resistance thermometer: 0.4°C (0.8°F)/

Ω max. (10 Ω max per line)

Insulation resistance

20 M

Ω min. (at 500 VDC)

Dielectric strength

600 VAC, 50/60 Hz for 1 min between current-carrying terminals of different polarity

Vibration resistance

10 to 55 Hz, 20 m/s2 for 2 hours each in X, Y, and Z directions

Shock resistance

150 m/s2, 3 times each in 6 directions

Weight

180 g

Degree of protection

Rear case: IP20, Terminal section: IP00

Memory protection

EEPROM (non-volatile memory) (number of writes: 100,000)

Standards Approved standards

UL61010C-1, CSA C22.2 No.1010-1

EMC Directive

EMI:

EN61326

EMI Radiated:

EN55011 Group1 class A

EMI Conducted:

EN55011 Group1 class A

EMS:

EN61326

ESD Immunity:

EN61000-4-2

Electromagnetic Field Immunity:

EN61000-4-3

Burst immunity/Noise Immunity:

EN61000-4-4

Conducted Disturbance Immunity:

EN61000-4-6

Surge Immunity:

EN61000-4-5

V1.2
