Introducing the E3ZM Series

E3ZM Standard Models (E3ZM-T/-R/-D/-LS) Ideal for the Food Industry, and Models for PET Bottle Detection (E3ZM-B).

Ratings and Specifications

* Values in brackets are the minimum required distance between the Sensor and Reflector.

Sensing method

Through-beam

Retro-reflective with MSR

function

Diffuse-reflective Models

Model

NPN output

E3ZM-T61

E3ZM-T66

E3ZM-T63

E3ZM-T68

E3ZM-R61

E3ZM-R66

E3ZM-D62

E3ZM-D67

Item

PNP output

E3ZM-T81

E3ZM-T86

E3ZM-T83

E3ZM-T88

E3ZM-R81

E3ZM-R86

E3ZM-D82

E3ZM-D87

Sensing distance

15 m

0.8 m

4 m [100 mm] * (Using E39-R1S)

3 m [100 mm] * (Using E39-R1)

1 m

(White paper 300

✕ 300 mm)

Spot diameter

---

Standard sensing object

Opaque: 12-mm dia. min.

Opaque: 2-mm dia. min.

Opaque: 75-mm dia. min.

---

Differential travel

---

20% of sensing distance max.

Reflectivity characteristics

(black/white error)

---

Directional angle

Emitter, Receiver: 3

° to 15°

Sensor: 3

° to 10°

Reflector: 30

°

---

Light source (wavelength)

Infrared LED (870 nm)

Red LED (660 nm)

Infrared LED (860 nm)

Power supply voltage

10 to 30 VDC, including 10% ripple (p-p)

Current consumption

40 mA max. (Emitter, Receiver: 20 mA max. each)

25 mA max.

Control output

Load power supply voltage: 30 VDC max., Load current: 100 mA max. (Residual voltage: 2 V max.)

Open-collector output (NPN/PNP output depending on model)

Light-ON/Dark-ON switch selectable

Protection circuits

Reversed power supply polarity protection, Output short-circuit

protection, and Reversed output polarity protection

Reversed power supply polarity protection, Output short-circuit

protection, Mutual interference prevention, and Reversed

output polarity protection

Response time

Operate or reset: 1 ms max.

Sensitivity adjustment

One-turn adjuster

Ambient illumination

(Receiver side) Incandescent lamp: 3,000 lx max., Sunlight: 10,000 lx max.

Ambient temperature range

Operating:

−25°C to 55°C, Storage: −40°C to 70°C (with no icing or condensation)

Sensing method

BGS Reflective Models

Models for PET Bottle Detec-

tion Retro-reflective (P-

opaquing and MSR Function)

Model

NPN output

E3ZM-LS61H

E3ZM-LS66H

E3ZM-LS62H

E3ZM-LS67H

E3ZM-LS64H

E3ZM-LS69H

E3ZM-B61

E3ZM-B66

Item

PNP output

E3ZM-LS81H

E3ZM-LS86H

E3ZM-LS82H

E3ZM-LS87H

E3ZM-LS84H

E3ZM-LS89H

E3ZM-B81

E3ZM-B86

Sensing distance

10 to 100 mm (White paper

100

✕ 100 mm)

10 to 150 mm (White paper

100

✕ 100 mm)

10 to 200 mm (White paper

100

✕ 100 mm)

100 to 500 mm

(Using E39-RP1)

Spot diameter

4-mm dia. at sensing distance

of 100 mm

12-mm dia. at sensing

distance of 150 mm

18-mm dia. at sensing

distance of 200 mm

---

Standard sensing object

---

Transparent round 500-ml PET

bottles (65 mm dia.)

Differential travel

3% of sensing distance max.

15% of sensing distance max. 20% of sensing distance max.

---

Reflectivity characteristics

(black/white error)

5% of sensing distance max.

10% of sensing distance max. 20% of sensing distance max.

---

Directional angle

---

Sensor: 3

° to 10°

Reflector: 30

°

Light source (wavelength)

Red LED (650 nm)

Red LED (660 nm)

Red LED (650 nm)

Power supply voltage

10 to 30 VDC, including 10% ripple (p-p)

Current consumption/

power consumption

25 mA max.

450 mW max.

Control output

Load power supply voltage: 30 VDC max., Load current: 100 mA max. (Residual voltage: 2 V max.)

Open-collector output (NPN/PNP output depending on model)

Light-ON/Dark-ON cable connection selectable

Protection circuits

Reversed power supply polarity protection, Output short-circuit protection, Mutual interference prevention, and Reversed output

polarity protection

Response time

Operate or reset: 1 ms max.

Sensitivity adjustment

---

Adjusted by teaching

Ambient illumination

(Receiver side) Incandescent lamp: 3,000 lx max., Sunlight: 10,000 lx max.

Ambient temperature range

Operating:

−25°C to 55°C, Storage: −40°C to 70°C (with no icing or condensation)

Operating:

−40°C to 60°C,

Storage:

−40°C to 70°C (with

no icing or condensation)
