E3S-C

8

Dimensions

Sensors

Note: Models numbers for Through-beam Sensors (E3S-CT11(-M1J)) are for sets that include both the Emitter and Receiver.

The model number of the Emitter is expressed by adding "-L" to the set model number (example: E3S-CT11-L 2M), the model number of the Receiver, by adding "-D"　

(example: E3S-CT11-D 2M.) Refer to Ordering Information to confirm model numbers for Emitter and Receivers.

(Unit: mm)

Tolerance class IT16 applies to dimensions in this datasheet unless otherwise specified.

50

*2

Light indicator (red)

Stability

indicator

(green)

22.2

9.2

4.2

6.2

38.2

8.3

29.5

17.3

25.4

20.8

2.2

4

18

9.3

23

Lens (17

× 11)

Optical axis

1.5

Two, M4

Stainless steel

(SUS304)

4.2

20

M3

× 5

4-dia. vinyl-insulated round cable

Standard length: 300 mm

M12

× 1

20.4

20

25.4

Two, M4

18.5

A*

1

*1. The Mounting Bracket can be attached to side A.

*2. The Emitters for Through-beam Sensors only have the power indicator (red).

*3. The Emitter cable is 4-dia.vinyl-insulated round cable with 2 conductors (conductor cross section: 0.3 mm2,

insulator diameter: 1.3 mm) and a standard length of 2 m.

4-dia. vinyl-insulated round cable with 3 conductors

(Conductor cross section: 0.2 mm2 (AWG 24),

Insulator diameter: 1.2 mm),

Standard length: 2 m *3

With Mounting Bracket Attached

Mounting Holes

Pre-wired Connector (-M1J)

Emitter: E3S-CT

@@-L

Receiver: E3S-CT

@@-D

Through-beam (Horizontal)

E3S-CT11(-M1J)
