[General Specifications]

Operating Ambient Temperature

Mounting Direction

Conforms to the CE Requirements

Conforms to the UKCA Requirements

Outer Dimensions

Refer to the Outer Dimension Drawing

Conformity Standards

RoHS Directive (EN IEC 63000)

EMC Directive (EN 61000-6-4, EN 61000-6-2)

Remarks

*1 Battery lifespan changes drastically, based on the operating environment conditions.

*2 The data is based on ambient temprature of 25 ℃, alkaline dry cell , and flash

pattern set at double flash.

Flashing Pattern

Double-flash / Single-flash

Peak luminous Intensity(Typ.)

Mass (Tolerance ±10%)

0.51 kg (Not including battery)

Power Mode:24hrs. *1 *2

Eco Mode:100hrs. *1 *2

Battery Lifespan

Less than 90 %RH No condensation (Battery is removed)

- 30 ℃ to + 60 ℃ (Battery is removed)

Less than 90%RH No condensation (Battery is removed)

Indoors and Outdoors

Upright ,Sideways (Power Switch is downward)

IP 55 (IEC 60529)

Model

Page

SPECIFICATIONS

Drawing No.

Rev.

PFH-BT-W18

E

PFH-BT-R

PFH-BT-Y

Red

Amber

Operating Ambient Humidity

Storage Ambient Temperature

Color

Rated Voltage

6VDC (4 - LR6 Alkaline dry cell batteries)

- 10 ℃ to + 50℃ (Battery is removed)

Storage Ambient Humidity

Mounting Location

Environmental

Condition

Upright

40cd (Power Mode)

140cd (Power Mode)

Protection Rating

Flashing Mode

Power Mode / Eco Mode

1/2
