56 / 139 page

RL78/D1A

3. ELECTRICAL SPECIFICATIONS (J GRADE PRODUCT)

R01DS0463EJ0120 Rev. 1.20

Page 56 of 135

Mar 31, 2026

TA = -40 to +85

°C, 2.7 V ≤ VDD ≤ 5.5 V, VSS = 0 V

Parameter

Symbols

Conditions

Typ.

Max.

Unit

WDT operating

current Note 1

IWDT

0.25

1.0

μA

ADC operating

current Note 2

IADC

Normal mode

VDD = 5.0 V

1.3

1.7

Low voltage mode

VDD = 3.0 V

0.5

0.7

LCD operating

Current Note 3

ILCD

fLCD = fSUB,

LCD clock = 512 Hz

VDD = 5.0 V

100

140

μA

VDD = 3.0 V

130

μA

ZPD operating

current Note 4

IZPD

One ZPD operated

VDD = 5.0 V

150

600

μA

VDD = 3.0 V

100

500

μA

Four ZPDs operated

VDD = 5.0 V

500

2000

μA

VDD = 3.0 V

400

1600

μA

Notes

1. Current flowing only to the watchdog timer. The maximum specification of IDD1, IDD2 and IDD3 include IWDT.

2. Current flowing only to the A/D converter. The current value of the RL78/D1A is the sum of IDD and IADC

when the A/D converter operates.

3. Current flowing only to the LCD controller/driver circuit. The current value of the RL78/D1A is the sum of IDD

and ILCD when the LCD controller/driver circuit operates.

4. Current flowing only to the ZPD circuit. The current value of the RL78/D1A is the sum of IDD and IZPD when

the ZPD circuit operates.
