ASSEMBLY

1. Place the left panel against the

rear panel and use the fixings

(machine screws, nuts and

washers) supplied to secure.

2. Repeat with the right panel and

the bottom panels.

3. Set the door in place as shown

making sure that the hinge pin is

inserted into the hole on the

bottom panel.

4. Fit the top panel and secure in

place using the fixings supplied.

•

The hinge pin on top of the door

must be inserted into the hole in

the top panel.
