HyperLink Wireless

900 MHz 8 dBi Flat Patch Antenna

for ISM, GSM, RFID and Wireless LAN Systems

Features

Applications:

900MHz ISM Band

Wireless LAN systems

GSM

RFID

SCADA

Wireless Video Links

900MHz Cellular

Features:

Superior performance

Light weight

Durable UV-stable, UL flame rated radome

Low loss solid brass elements

DC Short lightning protection

12 inch coax lead

Can be installed for either vertical or horizontal

polarization

Optional Mounting Kits available

RoHS Compliant

Model: HG908P

Product Description

Only 8.5 inches square!

Superior Performance

This high gain flat patch antenna provides 8 dBi gain with broad coverage. It is suitable for both indoor and outdoor wireless LAN

and wireless video applications in the 900MHz ISM band, GSM, 900MHz cellular and RFID applications.

Rugged and Weatherproof

This antenna's construction features sealed internal elements and an aesthetic UV-stable, UL flame rated white plastic radome.

Can be wall or mast mounted using U-bolts.
