Ordering information

Use the following steps to select the appropriate instrument and options for your measurement needs.

Step 1 – Select instrument model

Select the 2 Series instrument model

Model

Description

MSO22

Mixed Signal Oscilloscope: 2 analog channels, 2.5 GS/s sample rate, 10 Mpts record length

MSO24

Mixed Signal Oscilloscope: 4 analog channels, 2.5 GS/s sample rate, 10 Mpts record length

Each model includes

• TPP0200 200 MHz, 10:1 probe (one per channel)

• Instrument stand

• Installation and safety manual (translated in English, Japanese, and Simplified Chinese)

• Embedded help

• External power supply

• Calibration certificate documenting traceability to National Metrology Institute(s) and ISO9001/ISO17025 quality system registration

• One-year warranty covering all parts and labor cost on the instrument. One-year warranty covering all parts and labor cost on included probes

Step 2 – Configure bandwidth mandatory

Configure your oscilloscope by selecting the analog channel bandwidth you need. You can also upgrade the bandwidth later by purchasing an

upgrade option.

Bandwidth option

Bandwidth range

2-BW-70

70 MHz

2-BW-100

100 MHz

2-BW-200

200 MHz

2-BW-350

350 MHz

2-BW-500

500 MHz

Step 3 – Add instrument functionality

Instrument functionality can be ordered with the instrument or later as an upgrade kit.

Probes option

Description

2-P6139B

Add 500 MHz, 10x probes (one per channel)

2-MSO

Add MSO function with 16 digital channels; includes P6316 digital probe and accessories

2-BATPK

Battery pack with 2 battery slots and 1 battery (ships with instrument) for use with 2 Series oscilloscopes

Step 4 – Add instrument software functionality with one of the option bundles

Option bundles with different levels of functionality are being offered to suit different application needs.
