Data Sheet

ADL8201

TABLE OF CONTENTS

analog.com

Rev. 0 | 2 of 13

Features................................................................ 1

Applications........................................................... 1

Functional Block Diagram......................................1

General Description...............................................1

Specifications........................................................ 3

0.01GHz to 20GHz Frequency Range............... 3

20GHz to 30GHz Frequency Range.................. 3

Power Handling Capabilities.............................. 4

Absolute Maximum Ratings...................................5

Electrostatic Discharge (ESD) Ratings...............5

ESD Caution.......................................................5

Pin Configuration and Function Descriptions........ 6

Interface Schematics..........................................6

Typical Performance Characteristics..................... 7

Theory of Operation.............................................11

Applications Information...................................... 12

Outline Dimensions............................................. 13

Ordering Guide.................................................13

REVISION HISTORY

1/2026—Revision 0: Initial Version
