AD8565/AD8566/AD8567

Rev. D | Page 4 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Ratings

18 V

Input Voltage

Differential Input Voltage

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those listed in the operational sections

of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

Table 3.

Package Type

Unit

5-Lead SC70 (KS-5)

376

126

°C/W

8-Lead MSOP (RM-8)

210

45

°C/W

14-Lead TSSOP (RU-14)

180

35

°C/W

16-Lead LFCSP (CP-16-4)

382

302

°C/W

soldered onto a circuit board for surface-mount packages.

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the

human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
