HWS382

!

!

March 2004 V4

Hexawave Inc. 2 Prosperity Road II, Science Park, Hsinchu, Taiwan. TEL 886-3-578-5100 FAX 886-3-577-0512

http://www.hw.com.tw

All specifications are subject to change without notice.

Typical Performance Data with 8pF

Capacitors @ +25°C

Absolute Maximum Ratings

Parameter

Absolute Maximum

RF Input Power

+32 dBm @ +3V

Control Voltage

+6V

Operating Temperature

-40°C to +85°C

Storage Temperature

-65°C to +150°C

Pin Out (Top View)

Note:

RF ports.

2. Exposed pad in the bottom must be connected to

ground by via holes.

Logic Table for Switch On-Path

VC1

VC2

RFC-RF1

RFC-RF2

0

1

Insertion Loss

Isolation

1

0

Isolation

Insertion Loss

‘1’ = +3V to +5V

‘0’ = 0V to +0.2V

B

B

B

3

2

1

4

5

6

7

8

9

10

11

12

Isolation vs Frequency

-40

-35

-30

-25

-20

-15

-10

2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0

Frequency(GHz)

Insertion Loss vs Frequency

-0.7

-0.6

-0.5

-0.4

-0.3

-0.2

-0.1

2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0

Frequency(GHz)

Return Loss vs Frequency

-35

-30

-25

-20

-15

-10

-5

2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0

Frequency(GHz)
