Stepper motor drive current settings

MSE570

The motor phase current can be set to suit the motor to be driven by the use of the on-board DIP switch fitted to the

MSE570. The table below shows the nominal phase currents for each setting

Switch

Setting

Nominal Current

per phase

Typical

Motor

Motor

Connections

Typical Power Supply

consumption @

SW2-1

SW2-2

SW2-3

SW2-4

( Amps )

36 Vdc ( Amps )

off

off

off

off

0

off

off

off

on

0.5

1.0

off

off

on

off

0.9

17HS-020

4 lead

1.1

off

off

on

on

1.2

23HS-102

parallel

1.2

off

on

off

off

1.3

23HSX-102

parallel

1.3

off

on

off

on

1.6

1.4

off

on

on

off

1.85

17HS-240

4 lead

1.4

off

on

on

on

2.1

23HS-104

parallel

1.4

on

off

off

off

2.3

23HS-304

parallel

1.7

on

off

off

on

2.5

34HS-109

series

1.8

on

off

on

off

2.7

23HSX-202

parallel

1.9

on

off

on

on

2.9

34HS-106

parallel

2.0

on

on

off

off

3.0

34HS-209

series

2.1

on

on

off

on

3.1

23HS-309

series

2.1

on

on

on

off

3.3

34HS 109

series

2.3

on

on

on

on

3.5

23HSX-206

23HS-309

23HSX-306

34HS-109

34HS-209

34HSX-108

34HSX-208

34HSX-312

parallel

parallel

parallel

parallel

parallel

parallel

parallel

series

2.7

Recommended motor-drive-connection combinations shown in BOLD

Rack mounting power supply

MSE562

The MSE562 is designed for mounting in a 3U high Eurorack and is

ideal for use with the MSE570 drive card. The unit will power up to 2

small motor axes or a single axis using a 34HS size motor. For

applications requiring multi-axis operation using a combination of

motors requiring high current settings the MSE173 Power supply or

MSE875 units are recommended to drive up to 4 motors.

MSE562 provides a 35 Vdc motor rail for high speed operation

using the MSE570 Evo 2 drive.

Alternatively, where a motor is to be used at ultra high speed, the

MSE562’s 70 Vdc rail can be utilised in conjunction with a PM546

Drive

Specification

Width

142.2 mm ( 28E )

Depth

220

mm

Mounting

3U high rack installation

Connector

DIN41612 type D ( 32 way a & c )

AC Supply

230 / 115 Vac 50 or 60 Hz.

Outputs:

5V +0.25 V

1.5A Max

100mV ripple max.

24V + 2.0 V

1.0 A Max.

2.5 V ripple max.

35V +3.0 V

3.0A Max

4.0 V ripple max.

70V +3.0 V

2.0 A Max

14.0 V ripple max.

Connections: Refer to handbook
