89 / 104 page  4.1.5 Bill of materials (BOM) Referring to the Figure 16, Figure 29, Figure 30 and Figure 32, the Table 90 reports the bill of materials. Table 90. Bill of materials (BOM) Name Component Parameter Min Typ Max Unit TVS(1) TVS diode (battery transient protection) Breakdown voltage - 33 - V CIN(1) Input capacitor Capacitance - 1 - µF LERBST(1) ERBST inductor Inductance 27 33 39 µH DCR - - 1.5 Ω DERBST(1) ERBST diode Forward voltage - - 1.2 V RDCH(1) Discharge resistor Resistance - 68 - Ω CER1(1) Primary energy reserve capacitor (electrolytic) Capacitance 100 - 600 µF ESR 100 - 500 mΩ CER2(1) Secondary energy reserve capacitor (electrolytic) Capacitance 100 - 600 µF ESR 100 - 500 mΩ CVIO VIO bypass capacitor Capacitance - 100 - nF RFAULTN Pull-up resistor Resistance - 4.7 - kΩ CFAULTN Bypass capacitor Capacitance - - 1 nF CPF ESD/EMI capacitor Capacitance 13 22 138 nF CPR ESD/EMI capacitor Capacitance 13 22 138 nF Pyro-fuse model LWIRE Pyro-fuse wire load inductance Inductance - - 36 µH LEMI Pyro-fuse input EMI filter Inductance - - 7.7 µH RWIRE Pyro-fuse wire load resistance Resistance - - 1.1 Ω CPYRO Pyro-fuse differential capacitance between input contacts Capacitance - - 100 nF RPYRO Pyro-fuse igniter resistance Resistance 1.7 - 2.5 Ω 1. These components, based on application circuit, could not be mounted. L9965P Application scenarios DS14702 - Rev 4 page 89/104 |
|
