Data Sheet

ADL8143-CSL

SPECIFICATIONS

analog.com

Rev. 0 | 4 of 8

RADIATION TEST AND LIMIT SPECIFICATIONS

Electrical characteristics at VDD = 1.5V, IDQ = 35mA, RBIAS = 487Ω, and TCASE = 25°C, unless otherwise noted.

Table 4. Radiation Test and Limit Specifications

Parameter

Min

Typ

Max

Unit

FREQUENCY RANGE

10

14

GHz

GAIN

26.5

28.5

dB

OUTPUT

OP1dB

6.5

8.5

dBm

SUPPLY CURRENT

IDQ

35

mA

IDQ_AMP

33.2

mA

IRBIAS

1.8

mA

SUPPLY CURRENT

VDD

1.2

1.5

3.5

V
