Surface Mount Chip Resistor/ Capacitor

RC Network Series

Construction

08.20

General Note

TT Electronics reserves the right to make changes in product specification without notice or liability.

All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.

© TT Electronics plc

www.ttelectronics.com/resistors

BI Technologies IRC Welwyn

R/C Element

Alumina

Conductor

Nickel Barrier

Matte Tin

Glass Passivation

Outline Dimensions (Inch/mm)

4

4-61

Model RC Series

.252

±.008

6.40

±0.20

.126

±.008

3.20

±0.20

.022

±.004

0.55

±0.10

.041

±.008

1.05

±0.20

.012

±.008

0.30

±0.20

.050

±.008

1.27

±0.20

.032

±.008

0.80

±0.20

OUTLINE DIMENSIONS (Inch/mm)

2 Places

2 Places

.122

±.004

3.1

±0.1

.061

±.004

1.55

±0.1

.022

0.55

.018

±.008

0.45

±0.2

.014

±.006

0.35

±0.15

+0.10

-0.05

+.004

-.002

Model RC6

Model RC4

OBSOLETE
