Molded SMD Power Inductor

ASPI-F4030

4.1 x 4.1 x 2.8mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

Test Conditions

Isat: DC current at which the inductance drops 30% from its value without current.

Irms: DC current that causes the temperature rise (ΔT, approximate 40 ˚C) from 25°C ambient.

Operating Temperature: -55˚C ~ +125˚C (including self-temperature rise)

Storage Condition: -55˚C ~ +125˚C (on board), -10˚C ~ +40˚C (with packaging) and R.H. 70% max

ASPI-F4030 Series is RoHS Compliant and Pb free

Part Number

Inductance

Tolerance

DC Resistance

Saturation

Current

Temperature

Rise Current

0.1MHz/1.0V

Max

Typ.

Typ.

Typ.

Units

μH

%

mΩ

A

A

Symbol

L

M

DCR

Isat

Irms

ASPI-F4030-R47M-T

0.47

20

7.26

6.4

17

14

ASPI-F4030-R90M-T

0.9

20

10.1

8.9

10

11.2

ASPI-F4030-1R0M-T

1.0

20

10.1

8.9

9.8

11

ASPI-F4030-1R2M-T

1.2

20

11.5

10.1

9.2

9.8

ASPI-F4030-1R5M-T

1.5

20

13.2

11.6

8

9

ASPI-F4030-2R2M-T

2.2

20

22.6

20

7.0

7.8

ASPI-F4030-3R3M-T

3.3

20

28.6

25.3

6.2

6.6

ASPI-F4030-4R7M-T

4.7

20

44.1

38.8

4.5

5.1

ASPI-F4030-6R8M-T

6.8

20

74.1

65.2

3.6

3.9

 Shielded construction

 Soft saturation

 Low DCR, High Efficiency

 High temperature current rating

 Body electronics and comfort system

 Infotainment and entertainment

 Electric vehicles

 Lighting

 Solar inverters and power

 Industrial and robotics

 Medium and high-power switch mode power

supplies.

Electrical Specifications

Applications

Features
