SAP-10-R2

www.eravant.com | 424-757-0168 | support@eravant.com

Copyright © 2023 by Eravant

2/3

Rev 1.3

Mechanical Outline:

Unless otherwise specified, all dimensions are in inches [millimeters])

NOTE:

•

On condition that test data is provided it is collected from a sample lot. Actual data may vary slightly from unit to unit. All

testing is performed under +25 °C room temperature.

•

This antenna is a mature product. The reasons for only providing simulated data can be found in the following blog here.

•

Eravant reserves the right to change the information presented without notice.

CAUTION:

•

If a waveguide is present, any foreign objects in the waveguide will cause performance degradation and may damage or

destroy the unit.

•

Any foreign objects in the antenna will cause performance degradation and possible device damage.

•

For 1 mm connectors proper torque should be applied: 4.0 ± 0.15 inch-pounds (0.45 ± 0.02 Nm). Torque wrench model

SCH-06004-S1 is highly recommended.

•

For 1.35 mm, 1.85 mm, 2.4 mm, 2.92 mm, and SMA connectors proper torque should be applied: 8.0 ± 0.15 inch-pounds

(0.90 ± 0.02 Nm). Torque wrench model SCH-08008-S1 is highly recommended
