I-74

Digital Controller

E5CK

I Parameters Operation

Level 0 Mode

0

1 3 0 0

0

s p - m

50.0

o

c - o

50.0

r - 5

run

PV/SV

Set Point During SP Ramp

Monitors the set point when the SP ramp function is used.

MV Monitor (Heat)

MV Monitor (Cool)

Used when the Unit is in heating and cooling control operation.

Run/Stop

The process value is displayed on the No.1 display and the set point is displayed on the No.2 display.

When the multi-SP function is in use, the value of whichever is set, set point 0 or 1, is linked.

1

off

s e c r

k e y p

0

1

2

34

xxx

x

xx

x

xx

x

xx

x

xx

x

16.0

3 8. 8

Security

A/M Key Protect

Invalidate the function of the A/M Key.

MV Manual

Mode

Set value

Calibration

Option

Expansion

Setup

Level 2

Level 1, 0

Process value

Manipulated variable

MANU indicator

Any mode marked with "X" in the following table is not displayed on the menu when this parameter is set to

"0" to "3."

The Unit will be in only level 0 mode and the menu will not be available when this parameter is set to "4" to

"6."

Only the "PV/SP monitor" and "set point" parameter can be used when this parameter is set to "5."

Only the "PV/SP monitor" parameter can be used when this parameter is set to "6."
