Data Sheet

ADA4500-2

Rev. B | Page 7 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

(V−) − 0.2 V to (V+) + 0.2 V

Differential Input Voltage1

(V−) − 0.2 V to (V+) + 0.2 V

Output Short-Circuit Duration

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

1 Differential input voltage is limited to 5.6 V or the supply voltage + 0.6 V,

whichever is less.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead MSOP (RM-8)1

142

45

°C/W

8-Lead LFCSP (CP-8-11)2, 3

85

2

°C/W

1 Thermal numbers were simulated on a 4-layer JEDEC printed circuit board (PCB).

2 Thermals numbers were simulated on a 4 layer JEDEC PCB with the exposed

pad soldered to the PCB.

3 θJC was simulated at the exposed pad on the bottom of the package.

ESD CAUTION
